SENSECOM-CMNS

Product detailed description

Description:

SENSECOM-CMNS reads consumption (and supply if applicable) from SmartMeters (AMM) using HAN (P1) interface and sends data via a nationwide NB-IoT network. Powered by a rechargeable battery with occasional charging with a USB-C charger, or permanently with a USB-C charger.

Device inputs/outputs:

• HAN(P1) interface for AMM power meters

Basic features:

• Memory (datalogger) for least 1500 readouts
• E2E encryption with AES-256 possible
• > 12 months without battery recharging (with 2 transmissions and 2-12 readouts a day), Chargeable or permanently connected to USB-C
• Built in antenna (see also optional model with SMA connector for external antenna)
• small casing with IP20 protection
• Rechargeable battery (USB-C charger) 1-2 times per year (for e.g. 2-3 readings/transfers per day), or continuously powered by USB-C adapter for frequent readings (e.g. 15min intervals).
• Communication to the nationwide IoT network NB-IoT, NB-IoT coverage.
• Select optional multi-user multi-year flat rate (BUSINESS, SPM) for SENSEPARAM portal to access processed data, sending callbacks to your server, etc.

Advanced features:

• Setup registers to be read-out and sent (as provided by grid operator)
• manipulation detection (accelerometer)

Typical applications:

• Monitoring of power consumption and supply (if applied), different tarrifs (if applied), relays status (if applied) - intervals 15min-24h
• Monthly pre-payments adjustments, monthly/seasoning payments based on actual consumption.
• Leased facility/space utility consumption charging.

Download section:

available soon, eventually at smartimp.com web.
